Technical data (manufacturer information, German terms)
| Breite l1 | 50 |
|---|
| Länge l2 | 50 |
|---|
| Form | C - 2x2 Gewindestifte |
|---|
| Werkstoff | PA-HP - Polyamid PA-HP |
|---|
| d1 | M 6 |
|---|
| d2 | 6,5 |
|---|
| d3 | 6 |
|---|
| h1 | 11,5 |
|---|
| h2 | 6 |
|---|
| h3 | 6,5 |
|---|
| h4 ≈ | 13 |
|---|
| l3 | 18 |
|---|
| l4 | 12 |
|---|
| m1 | 30 |
|---|
| m2 | 30 |
|---|
| t | 3 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,046 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 237.1 |
|---|
| Order designation | GN 237.1-50-50-C |
|---|
| EAN | 4045525462823 |
|---|
| Manufacturer designation (German) | Scharniere, Kunststoff |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 39263000 |
|---|
| eCl@ss 5.1.4 | 23250304 |
|---|
