Technical data (manufacturer information, German terms)
| Fußdurchmesser d1 | 60 |
|---|
| Gewinde d2 | M 12 |
|---|
| Länge l1 (S/SK) | 100 |
|---|
| Form (Fußteller) | A0 - ohne Gummiauflage |
|---|
| Spindelvariante | S - ohne Mutter, Außensechskant unten |
|---|
| Werkstoff | ST - Stahl |
|---|
| h1 | 2,5 |
|---|
| m | 48 |
|---|
| d1 | 60 |
|---|
| d2 | M 12 |
|---|
| h3 | 11 |
|---|
| sw1 | 17 |
|---|
| Statische Belastbarkeit in kN Ausführung S / SK | 10 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,150 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 40 |
|---|
| Order designation | GN 40-60-M12-100-A0-S |
|---|
| EAN | 4045525035140 |
|---|
| Manufacturer designation (German) | Stellfüße, Stahl |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 73269098 |
|---|
| eCl@ss 5.1.4 | 90909090 |
|---|
