Technical data (manufacturer information, German terms)
| Gewinde d1 | G 3/8 |
|---|
| Werkstoff | PA - Kunststoff, Polyamid |
|---|
| d2 | 22 |
|---|
| l1 | 9 |
|---|
| l2 | 4 |
|---|
| s | 8 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,004 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 746 |
|---|
| Order designation | GN 746-G3/8 |
|---|
| EAN | 4045525369214 |
|---|
| Manufacturer designation (German) | Verschlussschrauben, Kunststoff |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 39235090 |
|---|
| eCl@ss 5.1.4 | 23111101 |
|---|
