Technical data (manufacturer information, German terms)
| Schauöffnung d1 | 30 |
|---|
| Zollgewinde d2 | G 1 1/4 |
|---|
| Form | B - ohne Reflektor |
|---|
| Werkstoff | PA - Kunststoff, Polyamid |
|---|
| d3 | 47 |
|---|
| l1 | 11,5 |
|---|
| l2 | 13 |
|---|
| s | 40,5 |
|---|
| empfohlenes Anzugsmoment in Nm | 8 ... 10 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,020 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 541 |
|---|
| Order designation | GN 541-30-G11/4-B |
|---|
| EAN | 4045525285620 |
|---|
| Manufacturer designation (German) | Ölschaugläser, Kunststoff |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 90261089 |
|---|
| eCl@ss 5.1.4 | 37011302 |
|---|
