Technical data (manufacturer information, German terms)
| Bohrung d1 | 6 |
|---|
| Länge l1 | 12 |
|---|
| Linksgewinde d21 | M 6L |
|---|
| Werkstoff | ST - Stahl |
|---|
| a | 12 |
|---|
| b | 6 |
|---|
| d3 | 10 |
|---|
| l2 | 24 |
|---|
| x12 | 36 |
|---|
| l3 | 31 |
|---|
| x13 | 43 |
|---|
| l4 | 9 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,010 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | DIN 71752 |
|---|
| Order designation | DIN 71752-6-12-M6L |
|---|
| EAN | 4045525359482 |
|---|
| Manufacturer designation (German) | Gabelköpfe, Stahl |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 73269098 |
|---|
| eCl@ss 5.1.4 | 90909090 |
|---|
