Technical data (manufacturer information, German terms)
| Bohrung d1 | 22 |
|---|
| Außendurchmesser d2 | 42 |
|---|
| Form | N - Bronze / Stahl nachschmierbar |
|---|
| Werkstoff | ST - Stahl |
|---|
| b1 | 28 |
|---|
| b2 | 20 |
|---|
| w Kippwinkel | 15° |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,267 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 648.8 |
|---|
| Order designation | GN 648.8-22-42-N |
|---|
| EAN | 4045525902961 |
|---|
| Manufacturer designation (German) | Gelenklager, Stahl |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 84833038 |
|---|
| eCl@ss 5.1.4 | 23050106 |
|---|
