Technical data (manufacturer information, German terms)
| Gewinde d1 | M 10 |
|---|
| k | 25 |
|---|
| Oberfläche | ELS - eloxiert, schwarz |
|---|
| Werkstoff | AL - Aluminium |
|---|
| d2 | 10 |
|---|
| d3 Gelenkbohrung | 6,5 |
|---|
| l1 | 46 |
|---|
| l2 | 33,5 |
|---|
| l3 | 20 |
|---|
| l4 | 12,5 |
|---|
| m | 17 |
|---|
| Laschengelenkset für d3 Form S | 511.1-M6-25-S |
|---|
| Laschengelenkset für d3 Form W | 511.1-M6-25-K |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,045 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 484 |
|---|
| Order designation | GN 484-M10-25-ELS |
|---|
| EAN | 4045525893849 |
|---|
| Manufacturer designation (German) | Anbau-Laschen-Klemmhalter |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 76090000 |
|---|
| eCl@ss 5.1.4 | 90909090 |
|---|
