Technical data (manufacturer information, German terms)
| Bohrung d1 | B 45 |
|---|
| Bohrung d2 | B 45 |
|---|
| Kennziffer | 2 - mit 3 Edelstahl-Zylinderschrauben DIN 912 |
|---|
| Oberfläche | BL - blank, matt gestrahlt |
|---|
| Werkstoff | AL - Aluminium |
|---|
| d3 | 65 |
|---|
| d4 | M 10 |
|---|
| l1 | 206 |
|---|
| l2 | 135,5 |
|---|
| l3 | 77,5 |
|---|
| m | 103 |
|---|
| z Schraubstellen | M10-50 |
|---|
| Zubehör empf. Klemmhebel GN 911 für z l4 | 92 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 1,351 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 198 |
|---|
| Order designation | GN 198-B45-B45-2-BL |
|---|
| EAN | 4045525772694 |
|---|
| Manufacturer designation (German) | Eck-Klemmverbinder, Aluminium |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 76090000 |
|---|
| eCl@ss 5.1.4 | 90909090 |
|---|
