Technical data (manufacturer information, German terms)
| Bohrung d | B 25 |
|---|
| Klemmlänge k | 50 |
|---|
| Oberfläche | SW - schwarz, RAL 9005, strukturmatt |
|---|
| Kennziffer | 2 - mit 2 Edelstahl-Zylinderschrauben ISO 4762 |
|---|
| Werkstoff | AL - Aluminium |
|---|
| l1 | 68 |
|---|
| l2 | 46 |
|---|
| l3 | 48 |
|---|
| z Schraubstellen | M8-35 |
|---|
| Zubehör empf. Klemmhebel GN 911 für z l4 | 63 | 78 |
|---|
| d1 / s | B - Bohrung |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,195 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 241 |
|---|
| Order designation | GN 241-B25-50-2-SW |
|---|
| EAN | 4045525650718 |
|---|
| Manufacturer designation (German) | Muffen-Klemmverbinder, Aluminium |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 76090000 |
|---|
| eCl@ss 5.1.4 | 90909090 |
|---|
