Technical data (manufacturer information, German terms)
| Breite b | 40 |
|---|
| Länge Winkel l2 | 40 |
|---|
| Winkelform | L - Winkel |
|---|
| Oberfläche | SW - schwarz, RAL 9005, strukturmatt |
|---|
| Kennziffer | 1 - mit Bohrung für Senkschrauben DIN 7991 |
|---|
| Werkstoff | ST - Stahl |
|---|
| l3 | 20 |
|---|
| Nutbreite | 40 |
|---|
| d | 8,3 |
|---|
| s | 5 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,105 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 967 |
|---|
| Order designation | GN 967-40-40-L-1-SW |
|---|
| EAN | 4045525866997 |
|---|
| Manufacturer designation (German) | Winkel, Laschen |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 73182900 |
|---|
| eCl@ss 5.1.4 | 90909090 |
|---|
