Technical data (manufacturer information, German terms)
| Gewinde d1 | M 4 |
|---|
| Länge l2 | 16 |
|---|
| Form | S - mit Zylinderschraube DIN 912 |
|---|
| Werkstoff | ZD - Zink-Druckguss |
|---|
| d2 | 7,5 |
|---|
| d3 | 6,9 |
|---|
| d4 | 7,5 |
|---|
| l3 | 11,5 |
|---|
| l5 | 4 |
|---|
| l6 | 4 |
|---|
| Laschen-Klemmhalter k-Maß | 16 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,011 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 511.1 |
|---|
| Order designation | GN 511.1-M4-16-S |
|---|
| EAN | 4045525892767 |
|---|
| Manufacturer designation (German) | Laschengelenksets |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 73182900 |
|---|
| eCl@ss 5.1.4 | 90909090 |
|---|
