Technical data (manufacturer information, German terms)
| d1 | D 25 |
|---|
| m1 | 100 |
|---|
| m2 | 100 |
|---|
| Form | A - mit Verbindungszapfen |
|---|
| Oberfläche | BL - blank, gleitgeschliffen |
|---|
| Werkstoff | AL - Aluminium |
|---|
| d2 | 30 |
|---|
| l1 | 120 |
|---|
| l2 | 120 |
|---|
| l3 | 54 |
|---|
| l4 | 32 |
|---|
| s | 5 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,224 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 197 |
|---|
| Order designation | GN 197-D25-100-100-A-BL |
|---|
| EAN | 4045525494190 |
|---|
| Manufacturer designation (German) | Monitorhalterungen, Aluminium |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 76090000 |
|---|
| eCl@ss 5.1.4 | 23159201 |
|---|
