Technical data (manufacturer information, German terms)
| Werkstoff/Oberfläche | NNI - Gehäuse Edelstahl |
|---|
| Größe | 30 |
|---|
| d1 Kugel | 30,1 |
|---|
| d2 | 45 |
|---|
| d3 | 55 |
|---|
| h1 | 23 |
|---|
| h2 | 13,8 |
|---|
| h3 | 7 |
|---|
| h4 | 4,5 |
|---|
| Tragzahl C in N Ausführung SBL | 2500 |
|---|
| SNI | 2000 |
|---|
| NNI | 2000 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,359 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 509.1 |
|---|
| Order designation | GN 509.1-30-NNI |
|---|
| EAN | 4045525458888 |
|---|
| Manufacturer designation (German) | Kugelrollen, Gehäuse Stahl / Edelstahl, mit Bund |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 84829900 |
|---|
| eCl@ss 5.1.4 | 90909090 |
|---|
