Technical data (manufacturer information, German terms)
| Durchmesser d1 | 35 |
|---|
| Gewinde d4 (Kennziffer 3) | M 6 |
|---|
| Form | KV - konvex |
|---|
| Kennziffer | 3 - Bolzen mit Innengewinde |
|---|
| Werkstoff | POM - Kunststoff |
|---|
| b1 | 10 |
|---|
| b2 | 8 |
|---|
| d5 | 14 |
|---|
| d6 | 14 |
|---|
| l3 | 12 |
|---|
| r | 90 |
|---|
| sw | T30 |
|---|
| t min. | 12 |
|---|
| Belastbarkeit radial dynamisch in N | 1000 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,043 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 753.1 |
|---|
| Order designation | GN 753.1-35-M6-KV-3 |
|---|
| EAN | 4045525758346 |
|---|
| Manufacturer designation (German) | Laufrollen, Kunststoff, mit Kugellager |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 83022000 |
|---|
| eCl@ss 5.1.4 | 90909090 |
|---|
