Technical data (manufacturer information, German terms)
| Höhe h1 | 43 |
|---|
| Form | E - Exzenterlaufrolle mit exzentrischem Lagerzapfen |
|---|
| Material Dichtung | 2RS - Kunststoff (NBR) |
|---|
| Werkstoff | ST - Stahl |
|---|
| b1 | 11 |
|---|
| b2 | 5 |
|---|
| d1 | 35 |
|---|
| d2 | 30,8 |
|---|
| d3 | 12 |
|---|
| d4 | M 6 |
|---|
| d5 | 10 |
|---|
| l1 | 4,3 |
|---|
| l2 | 2,5 |
|---|
| l3 max. | 0,7 |
|---|
| sw | 15 |
|---|
| t | 11 |
|---|
| x | 0,8 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,063 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 2426 |
|---|
| Order designation | GN 2426-43-E-2RS |
|---|
| EAN | 4045525960763 |
|---|
| Manufacturer designation (German) | Laufrollen |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 83024900 |
|---|
| eCl@ss 5.1.4 | 90909090 |
|---|
