Feste Ballengriffe DIN 39, Kunststoff – Ganter DIN 39-ST-32-D
Dimensional drawing Ganter DIN 39-ST-32-D
Preview: Feste Ballengriffe DIN 39, Kunststoff – Ganter DIN 39-ST-32-D
Preview: Dimensional drawing Ganter DIN 39-ST-32-D
Feste Ballengriffe DIN 39, Kunststoff
Feste Ballengriffe DIN 39, Kunststoff – Ganter DIN 39-ST-32-D
Dimensional drawing Ganter DIN 39-ST-32-D
Mobile Preview: Feste Ballengriffe DIN 39, Kunststoff – Ganter DIN 39-ST-32-D
Mobile Preview: Dimensional drawing Ganter DIN 39-ST-32-D

Feste Ballengriffe DIN 39, Kunststoff

Product No.:
39-ST-32-D
ca. 3-5 days ca. 3-5 days (abroad may vary)
manufacturer:
Ganter Norm
    You do not have permission to view the prices

    Prices and quantity discounts are shown after you log in. No customer account yet? Register now

    Add to wish list
    Description

    Technical data (manufacturer information, German terms)

    WerkstoffST - Stahl
    Griffdurchmesser d132
    FormD - mit zylindrischem Zapfen
    d2 Form D ST13
    GewindeM 12
    d420
    l1 ≈100
    l221
    l313
    sw Innensechskant6
    RoHSJa
    Gewicht0,368 kg

    Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.

    Article data

    ManufacturerGanter (Otto Ganter GmbH & Co. KG)
    Standard partDIN 39
    Order designationDIN 39-ST-32-D
    EAN4045525232921
    Manufacturer designation (German)Feste Ballengriffe Stahl, Kunststoff
    Order unitPiece
    Customs tariff number84879059
    eCl@ss 5.1.423010190
