Technical data (manufacturer information, German terms)
| Länge l1 | 117 |
|---|
| d1 | 8,5 |
|---|
| Oberfläche | WSA - weiß, RAL 9016, matt |
|---|
| Form | B - Montage von der Bedienseite |
|---|
| d2 | 26 |
|---|
| h1 | 39 |
|---|
| h2 | 18 |
|---|
| l2 | 143 |
|---|
| l3 min. | 91 |
|---|
| s | 8,5 |
|---|
| sw | 13 |
|---|
| t | 8,5 |
|---|
| Werkstoff | PA - Kunststoff, Polyamid |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,060 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 628.1 |
|---|
| Order designation | GN 628.1-117-8,5-B-WSA |
|---|
| EAN | 4045525668300 |
|---|
| Manufacturer designation (German) | Bügelgriffe, Kunststoff, antimikrobiell |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 39263000 |
|---|
| eCl@ss 5.1.4 | 23010103 |
|---|
