Technical data (manufacturer information, German terms)
| Griffbreite b1 | 20 |
|---|
| Länge l | 128 |
|---|
| Form | A - Montage von der Rückseite (Gewinde-Sackloch) |
|---|
| Oberfläche | BL - blank, gleitgeschliffen |
|---|
| Werkstoff | AL - Aluminium |
|---|
| a | 13 |
|---|
| b2 | 24 |
|---|
| b3 | 32 |
|---|
| b4 | 50 |
|---|
| b5 | 13,5 |
|---|
| Gewinde | M 6 |
|---|
| h1 | 32 |
|---|
| h2 | 48 |
|---|
| r | 13 |
|---|
| t min. | 10 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,111 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 565.2 |
|---|
| Order designation | GN 565.2-20-128-A-BL |
|---|
| EAN | 4045525295605 |
|---|
| Manufacturer designation (German) | Schräge Bügelgriffe, Aluminium |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 83024900 |
|---|
| eCl@ss 5.1.4 | 23010103 |
|---|
