Technical data (manufacturer information, German terms)
| Werkstoff | AL - Aluminium |
|---|
| Griffdurchmesser b | 36 |
|---|
| Länge l1 | 600 |
|---|
| Form | B - Montage von der Bedienseite |
|---|
| Oberfläche | SR - silber, RAL 9006, strukturmatt |
|---|
| a | 26 |
|---|
| Gewinde | M 10 |
|---|
| h1 | 71 |
|---|
| h2 | 16,6 |
|---|
| l2 | 655 |
|---|
| l3 | 40 |
|---|
| l4 | 13 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 1,480 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 428 |
|---|
| Order designation | GN 428-AL-36-600-B-SR |
|---|
| EAN | 4045525494367 |
|---|
| Manufacturer designation (German) | Maschinengriffe, Aluminium |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 83024900 |
|---|
| eCl@ss 5.1.4 | 23010103 |
|---|
