Technical data (manufacturer information, German terms)
| Handraddurchmesser d1 | 160 |
|---|
| Bohrungsdurchmesser d2 | 14 |
|---|
| Bohrungskennzeichnung | B - ohne Nabennut |
|---|
| Form | D - mit drehbarem Griff |
|---|
| Werkstoff | NF - Edelstahl-Feinguss |
|---|
| d3 | 31 |
|---|
| b | 11 |
|---|
| l1 | 20 |
|---|
| l2 ≈ | 35,5 |
|---|
| l3 ≈ | 70,5 |
|---|
| r | 71 |
|---|
| Ø Zylindergriff | 23 |
|---|
| Anzahl der Speichen | 3 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,920 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 949 |
|---|
| Order designation | GN 949-160-B14-D |
|---|
| EAN | 4045525551992 |
|---|
| Manufacturer designation (German) | Handräder, Edelstahl |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 84879059 |
|---|
| eCl@ss 5.1.4 | 23010301 |
|---|
