Technical data (manufacturer information, German terms)
| Handraddurchmesser d1 | 150 |
|---|
| Vierkant s1 | VK 12 |
|---|
| Farbe | SWK - schwarz, RAL 9005 |
|---|
| Werkstoff | ST - Stahlblech |
|---|
| s2 | 13,8 |
|---|
| d2 | 30 |
|---|
| l1 | 18 |
|---|
| l2 | 33,5 |
|---|
| Anzahl der Speichen | 3 |
|---|
| Blechstärke | 1,5 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,360 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 227.7 |
|---|
| Order designation | GN 227.7-150-VK12-SWK |
|---|
| EAN | 4045525562615 |
|---|
| Manufacturer designation (German) | Stahlblech-Handräder, für Armaturen |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 84819000 |
|---|
| eCl@ss 5.1.4 | 23010301 |
|---|
