Stahlblech-Handräder GN 227.6, für Armaturen – Ganter GN 227.6-ST-90-V9-SW
Dimensional drawing Ganter GN 227.6-ST-90-V9-SW
Preview: Stahlblech-Handräder GN 227.6, für Armaturen – Ganter GN 227.6-ST-90-V9-SW
Preview: Dimensional drawing Ganter GN 227.6-ST-90-V9-SW
Stahlblech-Handräder GN 227.6, für Armaturen
Stahlblech-Handräder GN 227.6, für Armaturen – Ganter GN 227.6-ST-90-V9-SW
Dimensional drawing Ganter GN 227.6-ST-90-V9-SW
Mobile Preview: Stahlblech-Handräder GN 227.6, für Armaturen – Ganter GN 227.6-ST-90-V9-SW
Mobile Preview: Dimensional drawing Ganter GN 227.6-ST-90-V9-SW

Stahlblech-Handräder GN 227.6, für Armaturen

Product No.:
227.6-ST-90-V9-SW
ca. 3-5 days ca. 3-5 days (abroad may vary)
manufacturer:
Ganter Norm
    You do not have permission to view the prices

    Add to wish list
    Description

    Technical data (manufacturer information, German terms)

    WerkstoffST - Stahlblech
    Handraddurchmesser d90
    Vierkant s0V 9
    OberflächeSW - schwarz, RAL 9005, matt
    s18,9
    s29,15
    l111
    l216
    Anzahl der Speichen3
    RoHSJa
    Gewicht0,076 kg

    Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.

    Article data

    ManufacturerGanter (Otto Ganter GmbH & Co. KG)
    Standard partGN 227.6
    Order designationGN 227.6-ST-90-V9-SW
    EAN4045525538962
    Manufacturer designation (German)Stahlblech-Handräder, für Armaturen
    Order unitPiece
    Customs tariff number84819000
    eCl@ss 5.1.423010301
