Technical data (manufacturer information, German terms)
| Kurbellänge l1 | 80 |
|---|
| Bohrung d1 | B 10 |
|---|
| Werkstoff | KU - Kunststoff |
|---|
| Bohrung | 10 |
|---|
| d2 | 14 |
|---|
| b1 | 20 |
|---|
| b2 | 24 |
|---|
| h1 | 20 |
|---|
| h2 | 26 |
|---|
| h3 ≈ | 40 |
|---|
| l2 | 30 |
|---|
| t min. | 16 |
|---|
| Ø Zylindergriff | 18 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,105 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 510 |
|---|
| Order designation | GN 510-80-B10 |
|---|
| EAN | 4045525267534 |
|---|
| Manufacturer designation (German) | Handkurbeln, Kunststoff |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 84879090 |
|---|
| eCl@ss 5.1.4 | 23010202 |
|---|
