Technical data (manufacturer information, German terms)
| Handraddurchmesser d1 | 100 |
|---|
| Bohrungsdurchmesser d2 | 10 |
|---|
| Bohrungskennzeichnung | B - ohne Nabennut |
|---|
| Form | D - mit drehbarem Griff |
|---|
| Werkstoff | KU - Kunststoff |
|---|
| d3 | 25 |
|---|
| d4 | 19 |
|---|
| d5 | 28 |
|---|
| b | 15 |
|---|
| l2 | 23 |
|---|
| l3 ≈ | 28 |
|---|
| l4 ≈ | 54,5 |
|---|
| r | 37 |
|---|
| {Sp:s} Ballengriff | 16 |
|---|
| Anzahl der Speichen | 3 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,139 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 555 |
|---|
| Order designation | GN 555-100-B10-D |
|---|
| EAN | 4045525292611 |
|---|
| Manufacturer designation (German) | Speichenhandräder, Kunststoff |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 84879090 |
|---|
| eCl@ss 5.1.4 | 23010390 |
|---|
