Technical data (manufacturer information, German terms)
| Handraddurchmesser d1 | 200 |
|---|
| Bohrung d2 | K 18 |
|---|
| Form | A - ohne Griff |
|---|
| Kennziffer | 1 - mit Lagerbuchse |
|---|
| Werkstoff | AL - Aluminium |
|---|
| Bohrung | 16 |
|---|
| Bohrung filtercolumn2 | 20 |
|---|
| b | 20,5 |
|---|
| l1 | 68 |
|---|
| l2 | 82,5 |
|---|
| r | 89 |
|---|
| {Sp:s} Zylindergriff | 26 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 2,011 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 327 |
|---|
| Order designation | GN 327-200-K18-A-1 |
|---|
| EAN | 4045525190986 |
|---|
| Manufacturer designation (German) | Sicherheits-Handräder,feststehender Lagerflansch |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 84879090 |
|---|
| eCl@ss 5.1.4 | 23010390 |
|---|
