Technical data (manufacturer information, German terms)
| Handraddurchmesser d1 | 70 |
|---|
| Bohrung d2 | B 10 |
|---|
| Form | D - mit drehbarem Knopf |
|---|
| Farbe der Abdeckkappe | DGR - grau, RAL 7035, matt |
|---|
| Werkstoff | PP - Kunststoff |
|---|
| Bohrung | 10 |
|---|
| d3 | 24 |
|---|
| d4 | M 5 |
|---|
| d5 | 16 |
|---|
| b | 21,5 |
|---|
| l1 | 42 |
|---|
| l2 | 25 |
|---|
| l3 | 23 |
|---|
| l4 | 6 |
|---|
| r | 25 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,088 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 735 |
|---|
| Order designation | GN 735-70-B10-D-DGR |
|---|
| EAN | 4045525637511 |
|---|
| Manufacturer designation (German) | Zustellräder, Kunststoff, farbige Abbdeckkappe |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 84879090 |
|---|
| eCl@ss 5.1.4 | 23010390 |
|---|
