Technical data (manufacturer information, German terms)
| Fußdurchmesser d1 | 60 |
|---|
| Gewinde d2 | M 16 |
|---|
| Länge l1 (T/TK) | 150 |
|---|
| Form (Fußteller) | C3 - poliert, Gummi aufvulkanisiert, schwarz |
|---|
| Spindelvariante | TK - mit Mutter, Schlüsselfläche unten |
|---|
| Werkstoff | NI - Edelstahl |
|---|
| h2 | 37 |
|---|
| s | 2 |
|---|
| sw2 | 12 |
|---|
| w in ° | 32 |
|---|
| x1 | 14 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,335 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 17 |
|---|
| Order designation | GN 17-60-M16-150-C3-TK |
|---|
| EAN | 4045525851634 |
|---|
| Manufacturer designation (German) | Stellfüße, Edelstahl 1.4301 (A2), FDA-konform |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 73269098 |
|---|
| eCl@ss 5.1.4 | 90909090 |
|---|
