Technical data (manufacturer information, German terms)
| Werkstoff | ST - Stahl |
|---|
| Handraddurchmesser d1 | 250 |
|---|
| Bohrungsdurchmesser d2 / s | 17 |
|---|
| Bohrungskennzeichnung | V - mit Vierkant |
|---|
| Farbe | SW - schwarz, RAL 9005, strukturmatt |
|---|
| Form | A - ohne Griff |
|---|
| s Vierkant | V 17 |
|---|
| b | 30 |
|---|
| d3 | 45 |
|---|
| l1 | 28 |
|---|
| l2 ≈ | 52 |
|---|
| Anzahl der Speichen | 5 |
|---|
| Blechstärke | 2,5 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 1,535 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 228 |
|---|
| Order designation | GN 228-ST-250-V17-A-SW |
|---|
| EAN | 4045525659889 |
|---|
| Manufacturer designation (German) | Handräder, aus Stahlblech |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 84819000 |
|---|
| eCl@ss 5.1.4 | 23010301 |
|---|
