Technical data (manufacturer information, German terms)
| Länge I | 80 |
|---|
| Vierkant s | V 10 |
|---|
| Form | D - mit drehbarem Griff |
|---|
| Werkstoff | GGG - Gusseisen (GGG) |
|---|
| e min. (Spalte 1) | 13,1 |
|---|
| Bohrung | 8 |
|---|
| d2 | 24 |
|---|
| h1 | 24 |
|---|
| h2 | 13 |
|---|
| h3 ≈ | 18 |
|---|
| h4 ≈ Form D | 61 |
|---|
| Form F | 56 |
|---|
| Ø Ballengriff | 18 |
|---|
| Bohrungskennzeichen | V - mit Vierkant |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,191 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | DIN 469 |
|---|
| Order designation | DIN 469-80-V10-D |
|---|
| EAN | 4045525259492 |
|---|
| Manufacturer designation (German) | Handkurbeln, Gusseisen |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 84879059 |
|---|
| eCl@ss 5.1.4 | 23010202 |
|---|
