Technical data (manufacturer information, German terms)
| Handraddurchmesser d1 | 160 |
|---|
| Bohrungsdurchmesser d2 | 14 |
|---|
| Bohrungskennzeichen | K - mit Nabennut DIN 6885-1 P9 |
|---|
| Form | F - mit festem Griff |
|---|
| Werkstoff | NI - Edelstahl-Feinguss |
|---|
| Durchmesser | 31 |
|---|
| d4 | M 10 |
|---|
| b | 17,5 |
|---|
| l1 | 20 |
|---|
| l2 ≈ | 39,5 |
|---|
| l3 | 77 |
|---|
| r | 62 |
|---|
| {Sp:s} Ballengriff | 25 |
|---|
| Anzahl der Speichen | 3 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 1,320 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 950.6 |
|---|
| Order designation | GN 950.6-160-K14-F |
|---|
| EAN | 4045525080508 |
|---|
| Manufacturer designation (German) | Handräder, Edelstahl |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 84879059 |
|---|
| eCl@ss 5.1.4 | 23010301 |
|---|
