Technical data (manufacturer information, German terms)
| Handraddurchmesser d1 | 60 |
|---|
| Gewinde d3 | M 12 |
|---|
| Form | D - mit Gewinde-Durchloch |
|---|
| Werkstoff | PA - Kunststoff, Polyamid |
|---|
| Bohrung | 12 |
|---|
| d4 | 25 |
|---|
| d5 | 24 |
|---|
| b | 16 |
|---|
| l1 | 23 |
|---|
| l2 | 30 |
|---|
| l3 | 11 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,108 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 527.1 |
|---|
| Order designation | GN 527.1-60-M12-D |
|---|
| EAN | 4045525277175 |
|---|
| Manufacturer designation (German) | Handräder, Kunststoff |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 84879090 |
|---|
| eCl@ss 5.1.4 | 23010301 |
|---|
