Technical data (manufacturer information, German terms)
| Außendurchmesser d1 | 44 |
|---|
| Bohrung d2 | K 10 |
|---|
| Form | B - mit 1 Verstellhebel |
|---|
| Werkstoff | ST - Stahl |
|---|
| Bohrung | B 10 |
|---|
| Bohrung filtercolumn1 | B 12 |
|---|
| d3 | 33 |
|---|
| d4 | 23 |
|---|
| d5 | 23 |
|---|
| d6 Teilkreis Ø für Befestigungsschrauben | 33 |
|---|
| l1 | 37 |
|---|
| l2 | 6 |
|---|
| l3 Bohrungslänge | 31 |
|---|
| l4 | 75 |
|---|
| w Ausrastweg | 4 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,497 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 200 |
|---|
| Order designation | GN 200-44-K10-B |
|---|
| EAN | 4045525078543 |
|---|
| Manufacturer designation (German) | Arretierelemente, Stahl |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 84879059 |
|---|
| eCl@ss 5.1.4 | 23010190 |
|---|
