Technical data (manufacturer information, German terms)
| Grifflänge l1 | 78 |
|---|
| Anschlussgewinde d1 | M 10 |
|---|
| Gewindelänge l2 | 16 |
|---|
| Farbe | SR - silber, RAL 9006, strukturmatt |
|---|
| Griffkoerpermaterial | ZD - Zink-Druckguss |
|---|
| d3 | 16 |
|---|
| d4 | 21 |
|---|
| h1 | 36 |
|---|
| h2 | 8 |
|---|
| h3 | 54 |
|---|
| h4 Rastweg | 4 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,135 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 300 |
|---|
| Order designation | GN 300-78-M10-16-SR |
|---|
| EAN | 4045525833487 |
|---|
| Manufacturer designation (German) | Verstellbare Klemmhebel, Zink-Druckguss, Schraube Stahl brüniert |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 84879090 |
|---|
| eCl@ss 5.1.4 | 23010501 |
|---|
