Dimensional drawing Ganter GN 6303.1-M6-NI
Preview: Schnellspann-Rändelmuttern GN 6303.1, Edelstahl – Ganter GN 6303.1-M6-NI
Preview: Dimensional drawing Ganter GN 6303.1-M6-NI
Schnellspann-Rändelmuttern GN 6303.1, Edelstahl
Schnellspann-Rändelmuttern GN 6303.1, Edelstahl – Ganter GN 6303.1-M6-NI
Dimensional drawing Ganter GN 6303.1-M6-NI
Mobile Preview: Schnellspann-Rändelmuttern GN 6303.1, Edelstahl – Ganter GN 6303.1-M6-NI
Mobile Preview: Dimensional drawing Ganter GN 6303.1-M6-NI

Schnellspann-Rändelmuttern GN 6303.1, Edelstahl

Product No.:
6303.1-M6-NI
ca. 3-5 days ca. 3-5 days (abroad may vary)
manufacturer:
Ganter Norm
    You do not have permission to view the prices

    Prices and quantity discounts are shown after you log in. No customer account yet? Register now

    Add to wish list
    Description

    Technical data (manufacturer information, German terms)

    WerkstoffNI - Edelstahl
    Gewinde d1M 6
    d224
    d316
    d46,7
    h14
    k10
    RoHSJa
    Gewicht0,037 kg

    Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.

    Article data

    ManufacturerGanter (Otto Ganter GmbH & Co. KG)
    Standard partGN 6303.1
    Order designationGN 6303.1-M6-NI
    EAN4045525480131
    Manufacturer designation (German)Edelstahl-Schnellspann-Rändelmuttern
    Order unitPiece
    Customs tariff number73181639
    eCl@ss 5.1.423110708
