Technical data (manufacturer information, German terms)
| Griffdurchmesser d1 | 60 |
|---|
| Gewinde d2 (Form E) | M 10 |
|---|
| Form | E - mit Gewinde-Sackloch |
|---|
| Werkstoff | KU - Kunststoff |
|---|
| d4 | 27 |
|---|
| h1 | 37 |
|---|
| h2 | 17 |
|---|
| t1 min. | 20 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,077 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 5337 |
|---|
| Order designation | GN 5337-60-M10-E |
|---|
| EAN | 4045525281325 |
|---|
| Manufacturer designation (German) | Sterngriffe, Duroplast, mit Messing-Buchse |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 39263000 |
|---|
| eCl@ss 5.1.4 | 23010102 |
|---|
