Technical data (manufacturer information, German terms)
| d1 | 50 |
|---|
| Gewinde d2 | M 8 |
|---|
| Drehmoment in Nm | 4 |
|---|
| Werkstoff | PA-HP - Polyamid PA-HP |
|---|
| d5 | 13,5 |
|---|
| d6 | 23,6 |
|---|
| h1 | 42 |
|---|
| h2 | 11 |
|---|
| t min. | 11 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,061 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 3664 |
|---|
| Order designation | GN 3664-50-M8-4 |
|---|
| EAN | 4045525569683 |
|---|
| Manufacturer designation (German) | Drehmoment-Dreisterngriffe |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 39263000 |
|---|
| eCl@ss 5.1.4 | 23031703 |
|---|
