Technical data (manufacturer information, German terms)
| Griffdurchmesser d1 | 54 |
|---|
| Gewinde d3 | M 10 |
|---|
| Gewindelänge l | 20 |
|---|
| Werkstoff | PP - Kunststoff |
|---|
| d4 | 20 |
|---|
| h1 | 30 |
|---|
| h2 | 12,5 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,060 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 4534 |
|---|
| Order designation | GN 4534-54-M10-20 |
|---|
| EAN | 4045525253841 |
|---|
| Manufacturer designation (German) | Rändelgriffschrauben, Kunststoff, Gewindestift Stahl, Softline |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 39263000 |
|---|
| eCl@ss 5.1.4 | 23010190 |
|---|
