Technical data (manufacturer information, German terms)
| Griffdurchmesser d1 | 12 |
|---|
| Gewinde d2 | M 5 |
|---|
| Gewindelänge l | 10 |
|---|
| Werkstoff | KU - Kunststoff |
|---|
| d3 | 9,5 |
|---|
| h | 11,5 |
|---|
| k | 7,5 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,003 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 591 |
|---|
| Order designation | GN 591-12-M5-10 |
|---|
| EAN | 4045525375055 |
|---|
| Manufacturer designation (German) | Rändelschrauben, Kunststoff |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 39263000 |
|---|
| eCl@ss 5.1.4 | 23110116 |
|---|
