Technical data (manufacturer information, German terms)
| Werkstoff | GG - Gusseisen |
|---|
| Griffdurchmesser d1 (GG) | 80 |
|---|
| Griffdurchmesser d12 (AL) | 80 |
|---|
| Form | A - Rohteil (unbearbeitet) |
|---|
| d4 | 25 |
|---|
| h3 | 52 |
|---|
| h4 | 30 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,380 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | DIN 6335 |
|---|
| Order designation | DIN 6335-GG-80-A |
|---|
| EAN | 4045525329881 |
|---|
| Manufacturer designation (German) | Kreuzgriffe, Rohteil, Gusseisen / Aluminium, ohne Bohrung |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 73259990 |
|---|
| eCl@ss 5.1.4 | 23010102 |
|---|
