Technical data (manufacturer information, German terms)
| Werkstoff (Schraube) | NI - Edelstahl |
|---|
| Gewinde d1 | M 8 |
|---|
| Gewindelänge l1 | 30 |
|---|
| Werkstoff (Druckzapfen) | MS - Messing |
|---|
| l2 MS-Zapfen | 1,5 |
|---|
| KU-Zapfen | 1,6 |
|---|
| d2 MS-Zapfen | 6 |
|---|
| Griffdurchmesser | 30 |
|---|
| k | 6 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,041 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 653.10 |
|---|
| Order designation | GN 653.10-M8-30-NI-MS |
|---|
| EAN | 4045525770508 |
|---|
| Manufacturer designation (German) | Rändelschrauben, Edelstahl, mit Messing / Kunststoff-Druckzapfen |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 73181595 |
|---|
| eCl@ss 5.1.4 | 23110116 |
|---|
