Technical data (manufacturer information, German terms)
| Gewindedurchmesser d1 | M 5 |
|---|
| Länge l1 | 38 |
|---|
| Form | A - ohne Schutzkappe |
|---|
| Werkstoff | ST - Stahl |
|---|
| d2 | 12,5 |
|---|
| h1 | 3,5 |
|---|
| h2 | 8 |
|---|
| l2 | 2,5 |
|---|
| m | 4,7 |
|---|
| sw | 8 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,008 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 807 |
|---|
| Order designation | GN 807-M5-38-A |
|---|
| EAN | 4045525376700 |
|---|
| Manufacturer designation (German) | Andrückschrauben, Stahl, mit / ohne elastische Schutzkappe |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 73181595 |
|---|
| eCl@ss 5.1.4 | 23110690 |
|---|
