Technical data (manufacturer information, German terms)
| Werkstoff | NI - Edelstahl |
|---|
| Größe | 55 |
|---|
| FH in N Haltekraft | 550 |
|---|
| b1 | 23 |
|---|
| b2 | 15 |
|---|
| b3 | 11 |
|---|
| b4 ≈ | 25 |
|---|
| b5 | 22 |
|---|
| b6 ≈ | 16 |
|---|
| d1 | 2 |
|---|
| d2 | 3,2 |
|---|
| h1 | 12 |
|---|
| h2 | 8 |
|---|
| l1 ≈ | 57 |
|---|
| l2 | 40 |
|---|
| l3 ≈ | 34,5 |
|---|
| m1 | 5,5 |
|---|
| m2 | 10 |
|---|
| m3 | 3,8 |
|---|
| m4 | 14 |
|---|
| r ≈ | 26 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,024 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 832.4 |
|---|
| Order designation | GN 832.4-55-NI |
|---|
| EAN | 4045525452534 |
|---|
| Manufacturer designation (German) | Spannverschlüsse, Stahl / Edelstahl |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 83089000 |
|---|
| eCl@ss 5.1.4 | 21020701 |
|---|
