Technical data (manufacturer information, German terms)
| Größe | 550 |
|---|
| Form | ASS - Druckspannung durch Rechtsdrehung |
|---|
| Werkstoff | MS - Messing |
|---|
| FH in N Haltekraft | 4500 |
|---|
| a | 20 |
|---|
| b | 32 |
|---|
| d1 | 14 |
|---|
| d2 | M 8 |
|---|
| d3 | 7 |
|---|
| h1 ≈ | 113 |
|---|
| h2 | 55 |
|---|
| l1 ≈ | 165 |
|---|
| l2 ≈ | 153 |
|---|
| l3 ≈ | 42 |
|---|
| m1 | 35 |
|---|
| m2 | 41 |
|---|
| m3 | 15 |
|---|
| m4 | 41 |
|---|
| s | 7 |
|---|
| t | 16 |
|---|
| w Hub | 42 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,700 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 844 |
|---|
| Order designation | GN 844-550-ASS |
|---|
| EAN | 4045525084421 |
|---|
| Manufacturer designation (German) | Schubstangenspanner, Stahl, für Druck- und Zugspannung |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 82057000 |
|---|
| eCl@ss 5.1.4 | 90909090 |
|---|
