Technical data (manufacturer information, German terms)
| Größe | 320 |
|---|
| Form | T - ohne Zugbügel, mit Gegenhalter |
|---|
| Werkstoff | ST - Stahl |
|---|
| FH in N Haltekraft | 3200 |
|---|
| a1 | 8 |
|---|
| a2 | 37 |
|---|
| b1 | 36 |
|---|
| b2 | 44 |
|---|
| b3 | 32 |
|---|
| b4 | 37 |
|---|
| b5 | 22 |
|---|
| d1 | M 6 |
|---|
| d2 | 6,5 |
|---|
| h1 | 54 |
|---|
| h2 | 15 |
|---|
| l1 ≈ | 106 |
|---|
| l2 min. | 6 |
|---|
| m1 | 25,5 |
|---|
| m2 | 8,5 |
|---|
| m3 | 19 |
|---|
| m4 | 10,5 |
|---|
| m5 | 20,5 |
|---|
| r ≈ bei w2 = 0 | 78 |
|---|
| s | 3 |
|---|
| w1 Hub | 53 |
|---|
| w2 ≈ Verstellweg | 21 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,270 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 851.1 |
|---|
| Order designation | GN 851.1-320-T |
|---|
| EAN | 4045525876712 |
|---|
| Manufacturer designation (German) | Verschlussspanner für Zugspannung |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 82057000 |
|---|
| eCl@ss 5.1.4 | 21020701 |
|---|
