Technical data (manufacturer information, German terms)
| Werkstoff | NI - Edelstahl |
|---|
| Bolzendurchmesser d1 | 8 |
|---|
| Form | AN - ohne Kontermutter, mit Edelstahl-Knopf |
|---|
| d2 | M 16 x 1,5 |
|---|
| d3 | 31 |
|---|
| l1 ≈ | 69 |
|---|
| l2 | 8 |
|---|
| l3 | 34 |
|---|
| Federdruck in N ≈ Anfang | 9 |
|---|
| Ende | 26 |
|---|
| Artikel-Nr. Schraubendreher | 613.1-8 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,123 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 613 |
|---|
| Order designation | GN 613-8-AN-NI |
|---|
| EAN | 4045525558366 |
|---|
| Manufacturer designation (German) | Edelstahl-Rastbolzen |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 73181900 |
|---|
| eCl@ss 5.1.4 | 23100190 |
|---|
