Technical data (manufacturer information, German terms)
| Bolzendurchmesser d1 | 6 |
|---|
| Aufnahmegewinde d2 | M 16 x 1,5 |
|---|
| Form | RK - mit Rastsperre, mit Kontermutter |
|---|
| Werkstoff | ST - Stahl |
|---|
| d3 | 16 |
|---|
| l1 ≈ | 51 |
|---|
| l2 | 8 |
|---|
| l3 min. | 35 |
|---|
| l4 | 32 |
|---|
| Federdruck in N ≈ Anfang | 6,5 |
|---|
| Ende | 20 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,060 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 712 |
|---|
| Order designation | GN 712-6-M16X1,5-RK |
|---|
| EAN | 4045525496415 |
|---|
| Manufacturer designation (German) | Kurven-Rastriegel, Raststift vorstehend |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 73182900 |
|---|
| eCl@ss 5.1.4 | 23100190 |
|---|
