Technical data (manufacturer information, German terms)
| Werkstoff | NI - Edelstahl |
|---|
| Bolzendurchmesser d1 | 6 |
|---|
| Form | AKN - mit Kontermutter, mit Edelstahl-Knopf |
|---|
| d2 | M 12 x 1,5 |
|---|
| d3 | 25 |
|---|
| e | 16,2 |
|---|
| l1 ≈ | 54,5 |
|---|
| l2 | 6 |
|---|
| l3 | 20 |
|---|
| l4 | 6 |
|---|
| l5 min. | 17 |
|---|
| sw | 14 |
|---|
| Federdruck in N ≈ Anfang | 8 |
|---|
| Ende | 21 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,077 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 617 |
|---|
| Order designation | GN 617-6-AKN-NI |
|---|
| EAN | 4045525558427 |
|---|
| Manufacturer designation (German) | Edelstahl-Rastbolzen |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 73181900 |
|---|
| eCl@ss 5.1.4 | 23100190 |
|---|
