Technical data (manufacturer information, German terms)
| Bolzendurchmesser d1 | 6 |
|---|
| Länge b | 35 |
|---|
| Form | C - mit Rastsperre |
|---|
| Kennziffer | 1 - Montage von vorne |
|---|
| Werkstoff | ZD - Zink-Druckguss |
|---|
| d2 | 4,3 |
|---|
| d3 | M 4 |
|---|
| d4 | 25 |
|---|
| h | 26 |
|---|
| k | 25 |
|---|
| l1 | 32 |
|---|
| l2 min. | 6 |
|---|
| l3 | 6 |
|---|
| l4 | 14 |
|---|
| s | 12 |
|---|
| sw | 12 |
|---|
| t | 10 |
|---|
| Federdruck in N ≈ Anfang | 5 |
|---|
| Ende | 15 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,069 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 412 |
|---|
| Order designation | GN 412-6-35-C-1 |
|---|
| EAN | 4045525037878 |
|---|
| Manufacturer designation (German) | Rastbolzen mit Anschraubflansch |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 73181900 |
|---|
| eCl@ss 5.1.4 | 23100190 |
|---|
