Technical data (manufacturer information, German terms)
| Bolzendurchmesser d1 | 10 |
|---|
| Feingewinde d2 | M 16 x 1,5 |
|---|
| Form | CN - mit Rastsperre, mit Edelstahl-Knopf |
|---|
| Werkstoff | NI - Edelstahl |
|---|
| d3 | 33 |
|---|
| d4 | 23 |
|---|
| l1 | 47,5 |
|---|
| Rastweg | 10 |
|---|
| l3 | 12 |
|---|
| k | 25,5 |
|---|
| sw | 17 |
|---|
| Federdruck in N ≈ Anfang | 11 |
|---|
| Ende | 35 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,113 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 822.7 |
|---|
| Order designation | GN 822.7-10-M16X1,5-CN |
|---|
| EAN | 4045525934672 |
|---|
| Manufacturer designation (German) | Edelstahl-Miniraster |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 73181900 |
|---|
| eCl@ss 5.1.4 | 23100190 |
|---|
