Technical data (manufacturer information, German terms)
| Schlüsselweite sw1 | 46 |
|---|
| Gewinde d1 | M 30 x 1,5 |
|---|
| Form | BR - Druckfläche plan, mit selbsttätiger Rückstellung |
|---|
| Werkstoff | ST - Stahl |
|---|
| d2 | 34,6 |
|---|
| d3 Kugel-Ø | 40 |
|---|
| e | 51 |
|---|
| l1 | 65 |
|---|
| l2 | 100 |
|---|
| sw2 | 46 |
|---|
| Statische Belastbarkeit max. in kN | 165 |
|---|
| RoHS | Ja |
|---|
| Gewicht | 0,884 kg |
|---|
Dimension letters (e.g. d1, l1) refer to the dimensional drawing in the product images; dimensions in mm.
Article data
| Manufacturer | Ganter (Otto Ganter GmbH & Co. KG) |
|---|
| Standard part | GN 709.3 |
|---|
| Order designation | GN 709.3-46-M30X1,5-BR |
|---|
| EAN | 4045525423220 |
|---|
| Manufacturer designation (German) | Pendelelemente, einstellbar, Stahl |
|---|
| Order unit | Piece |
|---|
| Customs tariff number | 84662020 |
|---|
| eCl@ss 5.1.4 | 21029090 |
|---|
